Sissejuhatus
We are the company specialized in the development, manufacturing, importing and distribution for Generating Sets up to 2000 Kva, Engines, Water Pumps and High Pressure Washers both gasoline and diesel powered. We are Licensee Company for HYUNDAI brand generators for more than 35 countries all over the world. We have developed a large range of Generating Sets and Engine pumps in order to cover all needs for professional and consumers. The firm was founded in EUROPE on 2001 by two partners with extensive experience in the international markets for machinery and especially the Generating Sets and Water Pumps. We are present In 5 continents and more than 50 countries with Europe, America, Oceania and Africa as our main markets.
Toote üksikasjad
Originaal: Jiangsu, Hiina
Certification: ISO9001 etc.
Hind: läbiräägitav
Maksetähtaeg: T / T, L / C
Tarneaeg: läbiräägitav
Pakkimine: eksportida standardpakendit
Turg: Lähis-Ida / Aafrika / Aasia / Lõuna-Ameerika / Euroopa / Põhja-Ameerika
Warranty: 1 year or warranty exclusive agreement
MOQ: 1 set
Tehnilised kirjeldused
| Engine & nbsp; Model | SD485 | SD 490 | SD 493 | SD 490Z | SD 493Z | SD4102 | SD4102Z | SD4102ZL |
| Püüdlus | Looduslik | Turboülelaadur | Looduslik | Turboülelaadur | Turbo + jahutamine | |||
| Põlemine | Direct & nbsp; injection | |||||||
| Kuberner | Mehaaniline | |||||||
| Silindri number | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Puur × käik (mm) | 85x100 | 90x100 | 93x102 | 90x100 | 93x102 | 102x115 | 102x115 | 102x115 |
| Maht (L) | 2.27 | 2.55 | 2.77 | 2.55 | 2.77 | 3.76 | 3.76 | 3.76 |
| Tihendussuhe | 19.1:1 | 17.5:1 | ||||||
| Nimivõimsus (KW) | 17/20/24 | 23/27/35 | 25/30/42 | 30/36/54 | 36/43/66 | 34/40/66 | 46/55/85 | 52/62/90 |
| r / min | 1500/1800/3000 | |||||||
| Maksimaalne tühikäigu kiirus（r / min) | ≤1575 | ≤1575 | ≤1575 | ≤1575 | ≤1575 | ≤1575 | ≤1575 | ≤1575 |
| Minimaalne - laadimiseta kiirus（r / min) | 800～850 | |||||||
| Fuel & nbsp; consumption（g / kW.h） | 245 | 245 | 245 | 240 | 230 | 245 | 245 | 245 |
| Jahutussüsteem | water & nbsp; cooling | |||||||
| Määrdesüsteem | Combined & nbsp; Pressure & amp; Splashing | |||||||
| Suurus (mm) | 735x585x637 | 825x623x788 | ||||||
| Silindri töö järjestus | 1-3-4-2 | |||||||
| Intake pipe & nbsp; diameter mm | ∅60 | ∅64 | ||||||
| Õli maht L | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
| Maximum oil & nbsp; temperature℃ | 120 | 120 | 120 | 120 | 120 | 120 | 120 | 120 |
| Starditüüp | 12 V - alalisvool | |||||||
| Flaywell - SAE | SAE 4 - 7, 5 0010010 # 39; & # 39; | SAE 3-10 / SAE 3 - 11, 5 0010010 # 39; & # 39; | ||||||
Ootan koostööd kliendiga kogu maailmas!
Kuum tags: vesijahutusega genset, Hiina, tootjad, tarnijad, tehas, hind
